2 - Characteristics
Tightening torques
To maintain the IP65 protection of the system and for optimal installation,
the following tightening torques must be used:
Component
DC input terminal block
13
95 mm
2
(Standard / -S version)
20.0 Nm
AC output terminal block 95 mm
2
20.0 Nm
Signal Terminal Block 1.5 mm
2
Max 2.5 Nm
Service cable gland
34
(PG 21)
7.5 Nm
DC cable glands
11
M32 (only Standard / -S versions)
8.0 Nm
AC cable gland M63 10.0 Nm
Ethernet cable gland (PG 21) 7.5 Nm
Ethernet cable gland (PG 16) 5.0 Nm
Protective earth terminal (external)
16
11.0 Nm
Protective earth terminal (internal)
37
11.0 Nm
Cable gland clamping range
Component
Service cable gland
34
(PG 21)
13...18mm
DC cable glands
11
M32 (Standard / -S versions)
13...21mm
AC cable gland M63 25...44mm
Ethernet cable gland (PG 21) 13...18mm
Ethernet cable gland (PG 16) 10...14mm
