- 119 -
000877BG
7 - Operation
NETWORK Services
In the NETWORK Services section it’s possible to access the following
sub-menus:
• RS485
• LAN
• WLAN
• Modbus
• Connectivity Check
• Debug Settings
RS485
In the RS485 sub-menu it’s possible to adjust the settings relating to the
RS485 communication serial line:
• RS485 Node Address: It allows you to sets the address for serial
communication of the individual inverters connected to the RS485
line. The UP and DOWN buttons scroll through the numerical scale.
(The addresses that can be assigned are 2 to 63).
• RS485 Baud Rate: It allows you to sets the Baud Rate (2400/4800/9
600/19200/34800/57600/115200).
• RS485 Parity Mode: It allows you to set the Parity bit (No Parity, Even
Parity, Odd Parity).
• RS485 Protocol Type: It allows you to sets the type of protocol to be
used for the RS485 line.
- “Modbus Sunspec Server”: General purpose communication pro-
tocol to be selected to enable monitoring and control.
- “Device Acquisition”: Communication protocol to be used in case
of connection in “Master” mode to external devices (like VSN800
weather station).
