ABB PVS-50-TL User Manual

- 17 -
000857BG
2 - Characteristics
Models and range of equipment
The choice of the inverter model must be made by a qualied technician
who knows about the installation conditions, the devices that will be installed
outside the inverter and possible integration with an existing system.
The models of three-phase inverters covered by this manual are divided
into two groups according to their maximum output power:
50kW and 60kW.
For each model, the following variants are available.
Inverter
Model Number
Description
PVS-50-TL
PVS-60-TL
• DC Terminal blocks. Single MPPT
• AC Terminal blocks
• SPD type II in both sides AC and DC monitored
PVS-50-TL-S
PVS-60-TL-S
• DC Switch
• DC Terminal blocks. Single MPPT
• AC Terminal blocks
• SPD type II in both sides AC and DC monitored
PVS-50-TL-SX
PVS-60-TL-SX
• 15 DC input via fast connectors
• 3 independent MPPT(parallel has to be possible)
• Protection fuses on POSITIVE pole only (state monitoring not included)
• DC Switch
• SPD type II in both sides AC and DC monitored
PVS-60-TL-SX-CN
• 12 DC input via fast connectors
• 3 independent MPPT (parallel has to be possible)
• Protection fuses on POSITIVE pole only (state monitoring not included)
• DC Switch
• SPD type II in both sides AC and DC monitored
PVS-50-TL-SX2*
PVS-60-TL-SX2*
• 15 DC input via fast connectors
• 3 independent MPPT (parallel has to be possible)
• Protection fuses on both poles (state monitoring not included)
• DC Switch
• SPD type II in both sides AC and DC monitored
All inverter models can be equipped with display by dedicated part number (“;DISPLAY” sufx)
* The SX2 versions can be equipped with SPD type I e II in DC side monitored by dedicated
part number (“;SPD1+2” sufx)
