Description Parameter
(channel 0)
Setting range Default setting Customer’s
setting
Analogue channel
conversion factor and unit
for I
L1
,I
L2
and I
L3
M80, M81, M82 Factor
0...65535, unit
(A, kA), e.g. 10,
kA
00001, CT
Analogue channel
conversion factor and unit
for the earth-fault current
M83 Factor
0...65535, unit
(A, kA), e.g. 10,
kA
00001, CT
Internal trigger signals'
checksum
V236 0...16383 682
Internal trigger signal's
edge
V237 0...16383 0
Checksum of internal
signal storing mask
V238 0...16383 751
Post-triggering recording
length
V240 0...100% 50 %
External trigger signal's
checksum
V241 0...31 0
External trigger signal's
edge
V242 0...31 0
Checksum of external
signal storing mask
V243 0...31 0
Table 8.-5 Auto-reclose parameters
Description Parameter
(channel 0)
Value Default setting Customer’s
setting
CB Closing time V121 0.1...10 s 0.2 s
Start delay of stage I> V122 0...300 s 300 s
Start delay of stage I0> V123 0...300 s 300 s
Reclaim time V124 3...300 s 10 s
Cutout time V125 0.1...300 s 0.1 s
Dead time of shot 1 V126 0.1...300 s 0.3 s
Dead time of shot 2 V127 0.1...300 s 30 s
Dead time of shot 3 V128 0.1...300 s 30 s
SG1 V129 0...255 0
SG2 V130 0...1023 0
SG3 V131 0...31 15
