Variable Group/
Channel 2
(R, W, P)
Setting range Default
setting
Custo-
mer ’s
setting
Checksum, SGL 6 2S96 0...8388607 0
Checksum, SGL 7 2S97 0...8388607 0
Checksum, SGL 8 2S98 0...8388607 0
Table 8.-3 Control parameters
Description Parameter
(channel 0)
Setting range Default setting Customer’s
setting
Rated frequency V104 50 or 60 Hz 50 Hz
Time setting range for
demand values in
minutes
V105 0...999 min 10 min
Non-volatile memory
settings
V106 0...31 31
Time setting for disabling
new trip indications on the
LCD
V108 0...999 min 60 min
Trip-circuit supervision V113 0 = not in use
1 = in use
0
Remote control of settings V150 0 = setting
group 1
1 = setting
group 2
0
Unit address of the relay V200 1...254 1
Data transfer rate (SPA),
kbps
V201 9.6/4.8 9.6
Rear communication
protocol
V203 0 = SPA
1 = IEC_103
2 = Modbus
RTU
3 = Modbus
ASCII
0
Connection type V204 0 = loop
1 = star
0
Line-idle state V205 0 = light off
1 = light on
0
Optional communication
module
V206 0 = not in use
1 = in use
0
Table 8.-4 Parameters for the disturbance recorder
Description Parameter
(channel 0)
Setting range Default setting Customer’s
setting
Sampling rate M15 800/960 Hz
400/480 Hz
50/60 Hz
800 Hz
Station identification/unit
number
M18 0...9999 0
Name of the feeder M20 Max 16
characters
