Variable Group/
Channel 2
(R, W, P)
Setting range Default
setting
Custo-
mer ’s
setting
Time multiplier n
0
2S15 1.0…15.0 1.0
Resetting time of stage I
0
> 2S16 0.05...2.50 s 0.05 s
Start value of stage I
0
>> 2S17 5.0...800% I
n
5.0% I
n
Operate time of stage I
0
>> 2S18 0.05...300 s 0.05 s
Start value of stage ΔI> 2S19 10...100% 100 %
Operate time of stage ΔI> 2S20 1...300 s 60 s
Full load current 2S21 0.30...1.50 x I
n
0.30 x I
n
Time constant of stage θ> 2S22 1...200 min 1 min
Alarm level of stage θ> 2S23 50...100% θt> 95% θt>
Operate time of CBFP 2S24 0.10...60.0 s 0.10 s
Number of AR shots 2S25 0 = AR is not in
use
1 = shot 1
2 = shot 1 and 2
3 = shot 1, 2 and
3
0
Current limit ArcI> of stage ARC 2S26 0.50...35.0 x I
n
2.50 x I
n
Current limit ArcI
0
> of stage ARC 2S27 5.0...800% I
n
20% I
n
Checksum, SGF 1 2S61 0...255 0
Checksum, SGF 2 2S62 0...127 0
Checksum, SGF 3 2S63 0...127 120
Checksum, SGF 4 2S64 0...63 0
Checksum, SGF 5 2S65 0...255 0
Checksum, SGB 1 2S71 0...1048575 0
Checksum, SGB 2 2S72 0...1048575 0
Checksum, SGB 3 2S73 0...1048575 0
Checksum, SGB 4 2S74 0...1048575 0
Checksum, SGB 5 2S75 0...1048575 0
Checksum, SGR 1 2S81 0...8388607 10922
Checksum, SGR 2 2S82 0...8388607 10922
Checksum, SGR 3 2S83 0...8388607 10922
Checksum, SGR 4 2S84 0...8388607 5461
Checksum, SGR 5 2S85 0...8388607 5461
Checksum, SGR 6 2S86 0...8388607 0
Checksum, SGR 7 2S87 0...8388607 0
Checksum, SGR 8 2S88 0...8388607 0
Checksum, SGL 1 2S91 0...8388607 0
Checksum, SGL 2 2S92 0...8388607 0
Checksum, SGL 3 2S93 0...8388607 0
Checksum, SGL 4 2S94 0...8388607 0
Checksum, SGL 5 2S95 0...8388607 0
