ABB RETA-01 User Manual

Communication
78
Instance 1 Attributes
ID# Attribute
name
Services Description Dflt,Min,Max Data type
0x01 Status Get 1 = The interface con-
figuration attribute con-
tains a valid
configuration
00000001h,
N/A, N/A
DWORD
0x02 Configuration
Capability
Get Interface configuration
attribute is adjustable.
Capable of obtaining
network configuration
via DHCP.
00000014h,
N/A, N/A
DWORD
0x03 Configuration
Control
Get/Set 0 = Configuration from
RETA-01 configuration
parameters;
2 = Configuration from
DHCP
N/A, 0, 2 DWORD
0x04 Physical Link
Object
Get Physical link -> Ethernet
object
Array[]
Path size 2 words 0x0002 UINT
Path Ethernet class, Instance
1
20 F6 24 01 Padded
EPATH
0x05 Interface
Configuration
Get/Set Array[]
Current IP
address
Module’s IP address N/A, N/A, N/A UDINT
Current sub-
net mask
Module’s Network mask N/A, N/A, N/A UDINT
Current gate-
way address
Module’s Gateway
address
N/A, N/A, N/A UDINT
Not used
Not used
Default
domain name
Default domain name
for not fully qualified
host names
N/A, N/A, N/A STRING
0x06 Host Name Get/Set Host name of the mod-
ule
N/A, N/A, N/A STRING
