42 CI/FSV/FSS/430/450-EN Rev. G | VortexMaster FSV430, FSV450 SwirlMaster FSS430, FSS450
Configuration of the current output
Not for devices with Modbus-communication!
Easy Setup
Output Value
Flow rate
Next Edit
1. Use to call up the edit mode.
2. Use / to select the desired process value for the
current output.
3. Confirm the selection with .
Configuration of the digital output
Easy Setup
DO Function
Logic on DO
Next Edit
1. Use to call up the edit mode.
2. Use / to select the desired operating mode for the
digital output.
Logic on DO: Operation as a switch output.
Pulse on DO: In pulse mode, pulses are emitted per unit.
Freq on DO: In frequency mode, a frequency proportional
to the flow is emitted.
3. Confirm the selection with .
Easy Setup Easy Setup
Pulses Per Unit Upper Freqency
0000001 /l 1.00 Hz
Next Edit Next Edit
4. Use to call up the edit mode.
5. With the help of / / set the pulses per unit
(Pulse on DO) or the upper frequency (Freq on DO).
6. Confirm the selection with .
Easy Setup Easy Setup
Pulse Width Lower Freqency
0000001 ms 1.00 Hz
Next Edit Next Edit
7. Use to call up the edit mode.
8. With the help of / / set the pulse width (Pulse
on DO) or the lower frequency (Freq on DO).
9. Confirm the selection with .
Easy Setup
Logic on DO
Normally Open
Next Edit
10. Use to call up the edit mode.
11. Select the switching behavior for the binary output with
/ .
12. Confirm the selection with .
Selection of the units
In the following menus, the units for the following process
values are selected: volume, mass, standard volume, power,
density, temperature, pressure, volume flowmeter, mass
flowmeter, standard volume flowmeter and energy meter.
Easy Setup
Unit
xx.xx
Next Edit
1. Use to call up the edit mode.
2. Use / to select the desired unit for the respective
process value.
3. Confirm the selection with .
