VortexMaster FSV430, FSV450 SwirlMaster FSS430, FSS450 | CI/FSV/FSS/430/450-EN Rev. G 45
6.5 HART variables
Factory settings of the HART variables PV, SV, TV and QV depending on the operating mode
The following table shows the factory assignment of the process variables to the HART variables (PV, SV, TV or Qv) depending
on the operating mode.
Operating mode HART variables
PV SV TV QV
Liquid Volume Operating volume Temperature Totalizer volumes
Liquid Std/Norm Vol. Standard volume Temperature Meter standard volume Operating volume
Liquid Mass Mass Temperature Totalizer mass Operating volume
Liquid Energy Energy Temperature Totalizer energy Operating volume
Gas Act. Volume Operating volume Temperature Totalizer volumes
Gas Std/Norm Vol. Standard volume Temperature Meter standard volume Operating volume
Gas Mass Mass Temperature Totalizer mass Operating volume
Gas Power Energy Temperature Totalizer energy Operating volume
Bio Act. Volume Partial operating volume Temperature Meter partial volume Operating volume
Bio Std/Norm Vol. Standard partial volume Temperature Meter standard partial
volume
Standard volume
Steam Act. Volume Operating volume Temperature Totalizer volumes
Steam/Water Mass Mass Temperature Totalizer mass Operating volume
Steam/Water Energy Energy Temperature Totalizer energy Mass
