44 CI/FSV/FSS/430/450-EN Rev. G | VortexMaster FSV430, FSV450 SwirlMaster FSS430, FSS450
Configuration of the alarm signaling via the current output
Not for devices with Modbus-communication!
Easy Setup
Iout at Alarm
High
Next Edit
1. Use to call up the edit mode.
2. Adjust the desired state in case of faults with / .
3. Confirm the selection with .
Easy Setup Easy Setup
High Alarm Value Low Alarm Value
21.000 m
A
3.600 m
A
Next Edit Next Edit
4. Use to call up the edit mode.
5. Use / / to set the alarm current.
6. Confirm the selection with .
Zero point adjustment of the flowmeter
NOTICE
Prior to starting the zero point adjustment, make sure that:
— There is no flow through the sensor (close valves, shut-
off devices etc.).
— The sensor is completely filled with the medium to be
measured
Easy Setup
A
uto Zero
Next Edit
— Use to start automatic adjustment of the zero point for
the system.
Configuration of the low flow cut-off
Easy Setup
Low Flow Cutof
f
0.000 %
Next Edit
1. Use to call up the edit mode.
2. Use / / to set the desired value for the low flow
cut-off.
3. Confirm the selection with .
Menu
Easy Setup
Exit Select
Once all parameter have been set, the main menu appears
again. The most important parameters are now set.
4. Use to switch to the process display.
Change from two to one column
