10.5 Required tools for installation
Parameter Specification
[mm] [in]
Philips screwdriver Size: PH2 Size: PH2
Slot screwdriver Size: 2.5 and 4.5 Size: 0.1 and 0.18
Hex keys Size: 5, 5.5 and 6 Size: 0.2, 0.22 and 0.24
Torx screwdriver Size: 15, 20 and 25 Size: 0.59, 0.79 and 0.98
Torx angled or bit with
ratchet
Size: 20 Size: 0.79
Open spanner Size: M5 (8 mm), M6 (10
mm), M10 (15mm), M12 (19
mm) and M16 (24 mm)
Size: M5 (0.31 in), M6 (0.39
in), M10 (0.59 in), M12 (0.75
in) and M16 (0.94 in)
Torque socket wrench 5 to 20 Nm, size M8 (13
mm) and M6 (10 mm)
5 to 20 Nm, size M8 (0.51
in) and M6 (0.39 in)
Ratchet spanner with
socket and extension
Size: M5 (8 mm) and M6
(10 mm)
Size: M5 (0.31 in) and M6
(0.39 in)
Voltage tester Standard
To make sure that the RCD works, press the test but-
ton on the RCD.
Digital multimeter Standard
Hoisting equipment or
forklift truck
Capable to lift the EVSE safely. Take into account the
dimensions, the mass, the center of gravity and the
maximum tilt angle. Refer to different sections in this
document.
Wire stripper pliers To strip the wires of the AC input cable
Cable lug tool Size: M10 (AC wires)
Size: M11 (PE wire)
10.6 Required parts for installation
Parameter
Specification
Swivel eye bolts or bolts with lifting
loops, to use with the hoisting equip-
ment
Thread M10
Cable lugs and fasteners Size: M10 (AC wires)
Size: M11 (PE wire)
Technical data
9AKK108466A3703-EN | 001 75
