10.7 Torque specifications
Parameter Specification
[Nm] [lb-in]
Fasteners for the PE wire Between 33 and 44 Between 292 and
389
Fasteners for the L1, L2, L3 wires Between 33 and 44 Between 292 and
389
Fasteners for an alternative base Between 33 and 44 Between 292 and
389
Fasteners for the tilt sensors 1.3 11.5
Fasteners for the cable management
system
Between 33 and 44 Between 292 and
389
10.8 Operating conditions
Parameter
Specification
SI units Imperial units
Environment, general Indoor and outdoor
Storage temperature -40°C to +70°C -40°F to +158°F
Operation temperature range -35°C to +50°C -31°F to +122°F
Maximum altitude above sea level 2000 m 6500 ft
Note: Operation of the EVSE outside the operating temperature ranges
and above the maximum altitude is not allowed and voids the product
warranty. The owner of the EVSE is responsible to ensure that the unit is
used within its operation range
10.9 Noise level
Noise level
Specification
Maximum noise level at a distance of 1 m
(3.2 ft)
< 62 dB(A)
10.10 Tilt sensor specifications
10.10.1 General specifications
Parameter
Specification
Voltage input 20..24 V DC
Power consumption Maximum 30 mA
Reverse polarity protection Yes
Isolation Rating 300 V
Technical data
76 9AKK108466A3703-EN | 001
