ABB TRIO-20.0/27.6-TL-OUTD

- 21 -
000047EG
2 - Characteristics
Table: Technical Data TRIO-20.0-TL-OUTD TRIO-27.6-TL-OUTD
Rated Output Frequency (fr) 50 Hz
Output Frequency Range (fmin...fmax) 47...53 Hz
(2)
Maximum apparent Output Power (Sacmax)
22200VA 30000 VA
The rated power Pacr is also guaranteed with cos() = 0.9
Rated Power Factor (Cosphiacr)
>0.995, adj. ±0.9 with
Pacr=20.0 kW,
± 0.8 with max 22.2kVA
>0.995, adj. ±0.9 with
Pacr =27.6 kW,
± 0.8 with max 30kVA
Total Harmonic Distortion of Current < 3%
Type of AC Connections Screw terminal board, maximum cross-section 35 mm
2
Output protection
Anti-islanding Protection In accordance with the local standard
Maximum AC Overcurrent protection
34.0 A 46.0 A
Output Overvoltage Protection - Varistors 4
Output Overvoltage Protection - DIN Rail surge arrester
(-S2X version)
4 (Class II)
Operating performance
Maximum Efciency (ηmax) 98.2%
Weighted Efciency (EURO/CEC) 98.0% / 98.0%
Power Input Threshold 40 W
Stand-by Consumption < 8W
NIght-time Consumption <1W
NIght-time Consumption (Reactive Power) 110 VAR
Inverter Switching Frequency 15.8 kHz
Communication
Wired Local Monitoring (opt.) PVI-USB-RS485_232 (opt.), PVI-DESKTOP (opt.)
Remote Monitoring (opt.) PVI-AEC-EVO (opt.), VSN 700 DATAOGGER (opt.)
Wireless Local Monitoring (opt.) PVI-DESKTOP (opt.) with PVI-RADIOMODULE (opt.)
User Interface Graphic Display
Environmental
Ambient Temperature -25...+60°C /-13...140°F with derating above 45°C/113°F
Storage Temperature -40...80°C (-40...+176°F)
Relative Humidity 0...100% condensing
Noise Emission < 50 db(A) @ 1 m
Maximum Operating Altitude 2000 m / 6560 ft
Environmental pollution classication for external environ-
ment
3
Environmental Category External
Physical
Environmental Protection Rating IP 65
Cooling system Natural
Overvoltage Category in accordance with IEC 62109-1 II (DC input) III (AC output)
Dimensions (H x W x D) 1061 x 702 x 292 mm 41.7” x 27.6” x 11.5”
Weight
Standard e -S2: 67kg / 147lb
-S2F / S2X: 75 kg / 165 lb
Standard e -S2: 72 kg / 158 lb
-S2F / S2X: 80 kg / 176 lb
Packaging Dimensions (H x W x D) 737 x 800 x 1200 mm / 29” x 31.5” x 47.2”
Full Packaging Weight
Standard e -S2: 79kg / 174lb
-S2F / S2X: 87 kg / 191 lb
Standard e -S2: 84 kg / 185 lb
-S2F / S2X: 92 kg / 202 lb
Mounting System Wall bracket
Exposure to UV rays
Plastic covers suitable for outdoor use.
Exposure to UV rays (in accordance with UL 746C)
Safety
Safety Class I
