ABB TRIO-20.0/27.6-TL-OUTD

- 27 -
000048DG
2 - Characteristics
TRIO-27.6-TL-OUTD-400
TRIO-27.6-TL-OUTD-S2-400
TRIO-27.6-TL-OUTD-S2F-400
TRIO-27.6-TL-OUTD-S2X-400
TRIO-27.6-TL-OUTD-400
TRIO-27.6-TL-OUTD-S2-400
TRIO-27.6-TL-OUTD-S2F-400
TRIO-27.6-TL-OUTD-S2X-400
30000
0
5000
10000
15000
20000
25000
Pout [W]
Vin [V]
0 100 200 300 400 500 600 700 800 900 1000
Pin1 (12800max) Vs Vin1
Pout Vs Vin
Pin2 (16000Wmax) Vs Vin2
Pin and Pout Vs. Vin1/Vin2
Independent input conguration (max channel unbalance)
30000
0
5000
10000
15000
20000
25000
Pout [W]
Vin [V]
0 100 200 300 400 500 600 700 800 900 1000
Pout Vs. Vin
Parallel input conguration
TRIO-20.0-TL-OUTD-400
TRIO-20.0-TL-OUTD-S2-400
TRIO-20.0-TL-OUTD-S2F-400
TRIO-20.0-TL-OUTD-S2X-400
0
5000
10000
15000
20000
25000
Pout [W]
Vin [V]
0 100 200 300 400 500 600 700 800 900 1000
Pin1 (8750max) Vs Vin1
Pout Vs Vin
Pin2 (12000Wmax) Vs Vin2
Pin and Pout Vs. Vin1/Vin2
Independent input conguration (max channel unbalance)
