Torch Service Center - TSC 2013 3HDA000057A8519-001 1-1
Assembly instructions
Overview
These assembly instructions describe the Torch Service Center TSC 2013, the torch cleaning sta-
tion TC 2013 and the add-on modules wire cutter and TCP measurement.
Please take information on each assembly from the corresponding chapter of the assembly
instructions.
These assembly instructions contain information on
• the mechanical structure of the TC/TSC 2013,
• assembly,
• electrical installation,
• operation, maintenance and repair.
Use these operating instructions
• in assembly of the TC/TSC 2013 (this also includes transport),
• in setting up and connecting,
• in using for the first time.
The documents on handover correspond to the latest position at the time of first use.
Only these operating instructions are relevant for the clarification of technical issues and ordering
of spare parts.
ABB does not accept liability if faults, damage, operating breakdowns and resultant production
failures occur through non-compliance with these assembly instructions.
Area of use
The TC/TSC 2013 is a tool of the robot and is controlled by the robot. It is used in robotic
MIG/MAG welding units
Chapter 1 Torch Service Center - TSC 2013
Chapter 2 Torch cleaner TC 2013
Chapter 3 Wire cutter
Chapter 4 TCP gauging (BullsEye
®
)
It is essential to read these assembly instructions
before using the TC/TSC 2013 for the first time, to
ensure safe handling of the product.
They should be read by all personnel who work with
this component or with systems this component is
built into.
The owner must make the assembly instructions avail-
able to the operator and make sure that the operator
has read and understood them.
Safety instructions must be followed!
