Appendix 2: Single-phase diagrams for VUCG/III and VUCL/III
Linear Plus/Minus Coarse/Fine
20 steps
Number of loops:
20 10 10 + 10
Number of tap positions:
21 21 21
21 steps
Number of loops:
21
Number of tap positions:
22
22 steps
Number of loops:
12 11 + 12
Number of tap positions:
23 23
24 steps
Number of loops:
12 12 + 12
Number of tap positions:
25 25
