ABB ZEE600 - Page 17

GUID-4222F0D0-D52B-4487-AC68-D39E53D8D2D6 V1 EN
Figure 6: System diagnostic dialog box
Table 1: System diagnostic symbols
Symbol
Description
GUID-18DF10F9-0285-43F7-8B1E-DC0214D7F9BB V1 EN
Personal computer
GUID-113C71EE-7496-48F1-BADC-A13702D01446 V1 EN
Server
GUID-3E124C60-196A-44A8-829F-CABEAA8115BB V1 EN
Network switch
GUID-5B2BF0B0-003B-4847-817A-8646E24B0AAD V1 EN
AC500 PLC
GUID-6B3CC53F-63F7-4C13-86A0-E11EFC2BAF48 V1 EN
Emax 2 circuit breaker
GUID-03C24190-E237-4F7F-8E92-14FA36B79B66 V1 EN
611 series protection and control relay
GUID-4C0B62B4-F8CD-445F-B3F3-285E4562EEE1 V1 EN
615 series protection and control relay
Table continues on next page
2NGA000149 A Section 2
ABB ZEE600 overview
ABB ZEE600 11
Operation Manual
