GUID-7F5F0D2A-894B-47D1-B733-6DC54869F9F2 V1 EN
Figure 25: Indication of insufficient user rights
A blocked command is indicated by a red lock icon and a grayed out background.
GUID-B006DF8E-A05A-40B1-B9B0-0CCE419DC35D V1 EN
Figure 26: Indication of interlocking active
3.5 Controlling tap changer
1. On the bay dialog box, select the MAIN tab.
2. Select the tap changer in the bay control field.
3.
Click or to move the tap changer up or down.
Section 3 2NGA000149 A
Operating the system
32 ABB ZEE600
Operation Manual
