Table 5: Energy management diagram control buttons
Name Description
Play Updates the screen
Stop Stops screen refreshing
Refresh search Refreshes the screen
Zoom Zooms the screen
Rezoom Reduces the screen
Zoom - Reduces the screen time intervals
Zoom + Increases the screen time intervals
Cursor on/off Queries values
<< Scrolls backward on the time axis (history)
>> Scrolls forward on the time axis (current)
Copy to clipboard Copies representation into the intermediate store
Diagram Displays the set filter
Settings Opens the dialog box for diagram settings and
cursor output
Print Prints the diagram
The diagram pane displays the trend curve and the cursor output list shows the cursor
position in the diagram pane, the values set in the diagram settings and the cursor
output.
Variable information is given as a list of curves that can be edited in Runtime.
• Active
• Color
• Area display
• Fill color
• Curve name
• Sorting order
• Title
• Transparency fill color
• Variable name
• Variable identification
• Y-axis
2.3 Bay dialog box
If a bay has been integrated into the visualization using Object Import Wizard, it is
possible to open the device-specific dialog box by selecting the corresponding bay on
an SLD page.
2NGA000149 A Section 2
ABB ZEE600 overview
ABB ZEE600 19
Operation Manual
