3.10.3.1 Defining new event filters
The filter dialog box has several settings that allow the event list to be filtered.
1. In Chronological Event List, click Filter to open the filter dialog box.
GUID-DD39E501-1F1C-4746-A69F-3A6BF97A4794 V1 EN
Figure 37: Opening the filter dialog box
2. Under Variable filter, define filter settings on the variable level.
Table 14: Variable filter
Item
Description
Variable name Filters by variable name
Identification Filters by variable identification
Case sensitivity Capitalization must be noted.
Show list without refresh Event list does not refresh.
Non-acknowledged alarms only Displays only unacknowledged alarms
Current alarms only Displays current alarms only
Only cleared alarms Displays cleared alarms only
Comment required Displays only alarms that require a comment
when acknowledged
Ring buffer Data comes from the ring buffer
Historic data Data comes from an archive
Maximum number Maximum number of historical alarms to be
displayed
0: displays all
3. Under Text filter, define the text filter properties.
