GUID-B2A4204A-C02D-4767-9124-A209653E973B V1 EN
Figure 36: Viewing events
The total number of alarms is displayed on the right side of the chronological
event list.
2. Filter the events, if necessary.
• Click Filter to open the filter dialog box to define new filter settings
(variables, time, text, alarm/event groups/classes, alarm areas and
minimum time active).
• In the Filter Profile list, select a filter to be applied.
• In Filter Profile text box, type a name and click Save to save the current
settings as a filter profile.
The filter profile name can be a maximum of 31 characters
long and must only contain valid characters. The
prohibited characters are: ! \ / : * ? < > | ""
• Click Import to import filter profiles from an export file.
• Click Export to export filter profiles in a file.
• Click Delete to delete the selected filter profile.
A comment about the selected event can be typed in the Comment field. The
maximum length of the text is 79 characters.
Click Stop to prevent new elements from being automatically
added to the event list.
Click Custom record to create an event without text to be used
for inserting an empty record for custom user comments.
Section 3 2NGA000149 A
Operating the system
44 ABB ZEE600
Operation Manual
