Figure 46: Selecting the IEC standard
3.18 Selecting electrical symbol alarms and text
1. On the main screen, select Utilities from the vertical menu.
2. Under Electrical alarms/text Standard, select the norm that applies to the
special device messages which have to follow a specific sentence structure.
• IEC61850
• IEC
• ANSI
3.19 Managing variables
In variable diagnosis, variables created in the project can be added to the displayed
table to view their actual values. The actual values of these variables can also be
manipulated.
The manipulation of variables can lead to unpredictable malfunction
of the connected devices and affect the usability and functionality of
2NGA000149 A Section 3
