Table 15: Text filter
Item Description
No text filter Does not select text filter
Search for (word separated by space) Activates the search
Search text Field for input of search term
Case sensitivity Capitalization must be noted.
Words do not need to appear in full within the
text
Fragments can also be searched for.
At least one word has to appear in the text At least one search term from several must be
in the result.
All words must be in the text All search terms must be included in the result.
Filter string must exactly be in the text Exact text from the input field must be
contained in the result.
4. Under Time filter, define the time filter properties.
Table 16: Time filter
Item Description
Filter type Dynamic text element for the display of the set
filter type
Current time Shows the current system time
From day/ hour/minute/second Fields and labeling for stating "from" time
Until day/ hour/minute/second Fields and labeling for stating "to" time
5. Under alarm/event groups/classes, alarms areas, define how alarms are
grouped and classified.
Table 17: Alarm/event groups/classes, alarm areas
Item
Description
Alarm/Event Groups Displays alarms or events of the same group
Alarm/event classes Displays alarms or events of the same class
Alarm areas List field for grouped display:
Alarm areas
If the property Use hierarchical alarming of the
Equipment Model is activated, the Alarm area
column is empty. The check box is in the alarm
handling item of the variable properties.
6. Under Minimum time active, define how recent events are displayed.
Section 3 2NGA000149 A
Operating the system
46 ABB ZEE600
Operation Manual
