GUID-722A571A-D321-4693-8C79-88E9F5686616 V1 EN
Figure 35: Opening the filter dialog box
2. Under Variable filter, define filter settings on the variable level.
Table 9: Variable filter
Item
Description
Variable name Filters by variable name
Identification Filters by variable identification
Case sensitivity Capitalization must be noted
Show list without refresh Alarm list does not refresh
Non-acknowledged alarms only Displays only unacknowledged alarms
Current alarms only Displays current alarms only
Only cleared alarms Displays cleared alarms only
Comment required Displays only alarms that require a comment
when acknowledged
Ring buffer Data comes from the ring buffer
Historic data Data comes from an archive
Maximum number Maximum number of historical alarms to be
displayed
0: displays all
3. Under Text filter, define the text filter properties.
Table 10: Text filter
Item
Description
No text filter Does not select text filter
Search for (word separated by space) Activates the search
Search text Field for input of search term
Table continues on next page
2NGA000149 A Section 3
Operating the system
ABB ZEE600 41
Operation Manual
