Figure 1. Correct vs. incorrect use of torque wrench
6. Insert the #2 torque wrench through the aperture on the header and into the setscrew on the side of the
6.
connector.
7.
Turn the wrench clockwise unl it clicks. The wrench is torque‑limited and when used correctly will not
7.
allow excessive ghtening.
8.
Repeat the steps above for addional leads.
8.
9.
Tug gently on the leads to ensure they are secured in the connector.
9.
In order to minimize device migraon, secure the device to the subcutaneous pocket via the suture hole in
the device header.
