Quick Installation
A-3
PN1 Pin 10-11:
There is no specific orientation for pin 10 and pin 11. Connect
the two-threads suspend switch connector of the computer case to correct pins
of header on the motherboard. You can ignore this connector since most of
computer cases do not support this feature (the motherboard itself supports it).
Pin number Name of the signal or signification
10 Ground
11 Suspend signal
PN2 Pin 1-2:
Attach the cable from the case’s Reset switch to this header.
Press and hold the reset button for at least one second to reset the system.
Pin number Name or significance of signal
1 Ground
2 Reset input
PN2 Pin 4-7:
There is no specific orientation for pin 4 and pin 7. Connect the
four-threads speaker cable to the PN2 header pins on the motherboard.
Pin number Name of the signal or signification
4 +5VDC
5 Ground
6 Ground
7 Speaker data
Watch the pin position and the
orientation
PN2 Pin 9-10:
There is a specific orientation for pin 9 and pin 10. Connect
the two-threads suspend LED switch connector of the computer case to correct
pins of header on the motherboard.
Installing suspend switch connector
Installing Hardware Reset Switch Connector
Installing speaker connector
Installing suspend LED connector
