3. Assembly / Installation
ATTENTION!
During installation, the camera must be disconnected from the mains voltage.
Site
The camera is suitable for indoor use only.
Do not place the camera near heaters, stoves, other heat sources or in direct sunlight.
Operate only in locations with temperatures within the allowable ambient temperature
range -10°~50°C.
3.1. Mounting the camera with wall bracket
During the installation of the camera, you have the option of accessing the following installation
instructions via the help in the app.
Drill mounting holes (6mm drill bit required) in the flat wall
surface using the drilling template, and attach the back plate
using the mounting material supplied.
Insert the ball joint, put on the cover and tighten it. Then put
on the fixing ring and tighten it slightly.
