System operation
13
System operation
General information
The device can be controlled as follows:
 By remote control
 Using the USB mouse
Operating elements on the device
Note
Pay attention to the overview on page 3.
No.
Name
Function
1
IR receiver
For the remote control
2
1: Switch to camera input 1
3
2: Switch to camera input 2
4
3: Switch to camera input 3
5
4: Switch to camera input 4
6
M
Opens or exits menu
Connections on the rear of the device
Note
Pay attention to the overview on page 3.
No.
Name
Function
7
Navigation buttons: Move within the menu
OK:
 Confirm in menu
 Press and hold for 5 seconds in live view to
activate or deactivate key lock
8
USB port
 To connect a USB mouse
 To connect a USB stick for data backups
9
VIDEO IN: 4x BNC inputs
10
VIDEO OUT 1: BNC monitor output
VIDEO OUT 2: BNC spot monitor output
11
AUDIO IN: Cinch audio input
AUDIO OUT: Cinch audio output
LINE IN: Cinch audio input
 Is for voicetransmitting via network. The
audio signal won´t to be recorded.
12
LAN:
10/100 MBit Ethernet LAN connection
13
VGA: VGA monitor output
14
RS 232: no function
15
ALARM IN:
 Alarm input 1–4
 G = Ground
ALARM OUT:
 Relay output and ground
RS-485:
Connection for PTZ cameras
16
12 V DC power socket
17
Power switch
