Angle Measurement Using Digital Angle Gauge
Head tube
Seat tube
Head tube beam
Alternative position for angle finder
when fixture is mounted in LCFF stand
Seat tube beam
Posion the angle nder as shown, so that it references the
main beam and BB carriage datum faces highlighted in green.
Ensure there is no debris on the beam and on the magnec
v-base of the angle nder.
Zero the readout.
Transfer the angle nder to the head tube or seat tube beam as required.
Do not ip the device 180 degrees (note the readout window is facing the same way as when
it was set to zero)
Ensure the front face of the angle nder is sll parallel to the main beam side datum to take
the reading.
To ensure the accuracy of the setup (and head tube roll calibraon) load a head tube and
seat tube into the xture and check the angles again by posioning the angle nder on these
tubes accordingly.
