ACADEMY LCFF 1.2 - Head Tube y Setting

LCFF 1.2 Setup & Calibraon
workshop manual v2
Page 8
© The Bicycle Academy Limited 2019
Head Tube Y Seng
H
e
a
d t
ub
e
Y
r
ea
d
i
ng
H
datum
e
a
d t
ub
e
Y
Insert the steel ruler as shown.
Push the ruler against the back plate if
necessary to reduce parallax.
Ensure the steel ruler references the
datum plate as shown.
If necessary push the ruler back
against the back plate, in the direcon
of the laser cut arrow.
