ACADEMY LCFF 1.2 - Table of Contents

Contents
1 — Introducon
1 — Important Calibraon Note
2 — Crate Contents
SETUP
3 — LCFF 1.2 General Assembly
4 — Measurement System
5 — Carriage Datums & Clamping
6 — Head Tube & Rear Axle X Seng
7 — Angle Measurement Using Digital Angle Gauge
8 — Head Tube Y Seng
9 — Rear Axle Height Seng - BB DROP
10 — Rear Axle Height Seng - BB RISE
CALIBRATION
11 — Laser Pointer Calibraon
12 — Degrees of Freedom
13 — Correct Grub Screw Adjutment
14 — Calibraon Step 1 - Seat Tube Centre Line
15 — Calibraon Step 2 - Head Tube Centre Line & Roll
16 — Calibraon Step 3 - Rear Axle Centre Line & Roll
17 — Calibraon Step 4 - Rear Axle Yaw
BUILD
18 — Head Tube Pucks & Adaptors
19 — Boom Bracket Adapters & Dummy Axle Setup
