ACADEMY LCFF 1.2 - LCFF 1.2 General Assembly

LCFF 1.2 - General Assembly
LCFF 1.2 Setup & Calibraon
workshop manual v1
Page 3
© The Bicycle Academy Limited 2019
LCFF 1.2 Setup & Calibraon
workshop manual v1
Page 3
© The Bicycle Academy Limited 2019
E
F
D
G
C
B
A
402400 66 H
Chain Stay length
Horizontal
LCFF
Head Tube X
LCFF Head Tube Y
Seat angle
Head angle
Bottom Bracket
Drop/Rise
1730
400
LCFF No. Description QTY. Pack
A Main Beam Assembly 1 A
B Front Axle Carriage Assembly 1 B
C  1 C
D Rear Axle Carriage Assembly 1 D
E Head Tube Carriage Assembly 1 E
F Seat Tube Carriage Assembly 1 F
G  1 G
H  3 H
66  1
400
Steel ruler 25 mm wide 1
402
 4
