ACADEMY LCFF 1.2 - Measurement System

LCFF 1.2 Setup & Calibraon
workshop manual v2
Page 4
© The Bicycle Academy Limited 2019
Measurement System
Chain Stay length
Horizontal
BB axis to Steering axis intersect
LCFF Head Tube X
Horizontal
(Henry James X in BikeCAD)
LCFF Head tube bottom
from BB horizontal plane
along steering axis
(Henry James Y in BikeCAD)
Seat angle
Head angle
Bottom Bracket
Drop/Rise
