38 Access Sensor Technologies UPAS User Guide
Table 5 Sample Run Sequence
Sequence Item UPAS Status Indicator Definition
Connect to UPAS using
App for setup
Blue (cyan) light on UPAS successfully connected to the mobile App.
Setup App parameters Blue (cyan) light on Setup all sample configuration parameters in the App
Delayed Start Time
Orange light flashes
repeatedly
GPS is off or no GPS date/time is set.
Blue (cyan) light flashes
once
GPS Date/Time set and satellite signal is available.
Magenta light flashes
once
GPS Date/Time set but signal not currently available.
Start at Next Power-on
UPAS Indicator light turns
off after starting UPAS
sample.
UPAS is sleeping; it starts sampling at next Power-On.
Wake Up for delayed
start sampling
UPAS Indicator light turns
on.
UPAS is about to start sampling using the pre-sleep App
programmed settings. All Start-up Sequence lights apply
except Pink light (waiting for App to connect).
GPS Options
Pink light on GPS is turned on (see App instructions. See Chapter 2).
Orange light on GPS is turned off (see App instructions. See Chapter 2).
Optional. Download
logged data from
previous sample
Red light on Log file download is initializing.
Orange light on Log file download in progress.
Blue (cyan) light on Log file download is complete.
