132
KNOB DISPLAY
In an active menu, SYSTEM KNOB DISPLAY offers different display option for parameters that
have knobs assigned to them:
LED MODE
Here you can chose between two operating modes for the RATE LEDs of LFO 1 and 2:
Mode Description
OFF
Knob movements are not displayed; the current contents of the display
remain intact when you turn a knob.
SHORT
When you turn a knob, the current contents of the lower display line are
briefly overwritten by data representing the change in parameter value;
once the action is completed, the original contents reappear in the lower
display line.
LONG
Same as SHORT, except that - you guessed it - the display shows the knob
data for a longer period of time.
ON
The contents of the display are overwritten when you turn a knob; the orig-
inal menu does not reappear in the display.
Mode Description
LFO
The LEDs indicate the oscillations of the LFOs.
INPUT
The LEDs serve as level indicators for the two external audio inputs (RATE
1 = Input L; RATE 2 = Input R). The brightness of the LEDs indicates the
current input level; signal saturation is indicated by rapidly flashing LEDs.
To achieve maximum sound quality for the system, you should set the input
signal to a level that is as close as possible to the saturation threshold.
However you should avoid setting the level beyond the saturation thresh-
old, otherwise you will hear undesirable distortion in the signal. You can
also use the level indicators to see if an input signal is actually patched in.
AUTO
When you activate AUTO, the LFO Rate LEDs will automatically indicate
the input level when you switch to a SINGLE or PART that accesses an
external audio outputs.
OUTPUT1
Level of Ouput 1
