2-10 System Components User Manual
Figure 2.32 Central Alarm
Central Alarm
The Central Alarm (Figure 2.32) is a multi-tone alert. It consists of
a tone generator that drives Speakers (up to 5) located throughout
a facility. There are eight different tones available. You may
choose to assign a separate tone for each zone, share the same
tone for adjacent zones, or use one tone for all zones.
Figure 2.33 Speakers
Speakers
The 8-ohm Speakers (Figure 2.33) provided by Accutech are used
in conjunction with the Central Alarm.
Figure 2.34 Voice Alarm
Voice Alarm
The Voice Alarm (Figure 2.34), located at a monitored zone, will
repeat a recorded message (up to 20 seconds) continuously when
an alarm occurs.
Figure 2.35 Strobe Light
Strobe Light
A Strobe Light (Figure 2.35) can be used as another alarm
notification device.
Figure 2.36
Push Button Override (PBO)
Push Button Override (PBO)
The Push Button Override (PBO) (Figure 2.36) triggers the
Keypad’s Escort function; this option allows free access through
a monitored door from the non-Keypad side of the door.
Figure 2.37 Timer example
Timer
A Timer (Figure 2.37) allows the user to engage or disengage
certain system functions on a time schedule.
