3-2 Tags User Manual
BR 4200 System Tags
In addition to the functionality of an IS 3200
System Tag, BR 4200 System Tags (Figure
3.3) will alarm if the band is removed or
tampered with in any way.
BR 4200 System Tags also contain a visual
pulse LED. Tags are activated/deactivated
with an S-TAD unit.
BR 4200 System Tags are attached to
infants with a conductive-fiber-striped cloth
band.
Figure 3.3 BR 4200 System Tag
Cut Band Tags
Similar to the functionality of a BR 4200
System Tag, Cut Band Tags (Figure 3.4) will
alarm if the band is cut, removed, or
tampered with in any way and is designed
for use in pediatric applications. Cut Band
Tags also contain a visual pulse LED.
The band (Figure 3.5) accommodates
various wrist/ankle lengths.
Using a pod (Figure 3.6) with a Cut Band
Tag will significantly reduce the need for
sanitizing the Tag between applications and
is water-resistant during use.
Figure 3.4 Cut Band Tag
Figure 3.5 Cut Band Band
Figure 3.6 Cut Band Pod
