Chapter 1: The LC1400 System 1-12
Typical LC1400 Configuration - Hallway
~2’
above-
floor
~2’
above-
floor
KP103
Keypad
Part #650209
15VDC/2A Plug-in
Power Supply
Part #500224
Passive Infrared
Reader
Part #300302
LC1400
Part #66022
Controller
LCT-TX
Only
Part #672022
Important:
15VDC/2A Plug-in Power
Supply
(Part #500224):
•Installed above drop ceiling
Passive Infrared Reader
(Part #300302)
• Position facing down
toward floor
LC1400T / LCT-TX
•Not designed for ceilng
mount.
•Position at least 3” away
from any metal.
LCT Hallway/Elevator Kit
(Part #800128:
•LC2400T (1)
•LCT-TX (1)
•Keypad (1)
•Passive Infrared Reader (1)
•Cable Kit (1)
•15VDC/2A Power Supply (1)
