Chapter 2: The LC1400T 2-10
Terminals
J1 (Power)
J1-1 (Power for board)
Unregulated 15VDC
J1-2 (Ground for board)
TB1 (Keypad)
TB1-1 (Reset All In)
12VDC In resets LC1400T/Lock
TB1-2 (Alarm)
11.5 VDC @ 50 ma
TB1-3 (Reset Lock In)
Resets Lock Only with Low Input
TB2 (Lock)
TB2-1 (Power for Lock)
15VDC @ 600ma
TB2-2 (Ground for Lock)
TB2-3 (Lock Trigger)
Active Low on Tag Detected
TB2-4 (Reset to Lock)
Active Low Out when Reset Lock In Active
TB3 (PIR/Magnetic Switch)
TB3-1 (PIR/Magnetic Switch-In)
TB3-2 (PIR Power/Magnetic Switch-Out)
11.5 VDC @ 20 ma
TB4 (Perimeter)
Perimeter function active with 11.5VDC In
TB4-1 (Perimeter In)
TB4-2 (Perimeter Out)
11.5VDC @ 20ma
JP1 - 120 Ohm Terminating Resistor
J2 RS485 Connection
B,A, Ground
See 7-2. Figure 7.1
Used to configure or change settings in the
LC1400T or LCT-TX only.
