Seagate PC-3000 EXPRESS / UDMA / PORTABLE 
F3 architecture  ACE Lab
Technical support: ts@acelab.ru
Phone: +7 863 201 50 06
24 ts.acelaboratory.com
1099 0 0 04 005041 000000 1 00000080 SRV_MEM Type 6 Addr 000000E7 Cnt 0001
1099 0 1 04 005041 000000 1 00000080 SRV_MEM Type 8 Addr 040019A8 Cnt 0004
1100 1 0 04 005041 000000 1 00000080 SRV_MEM Type 6 Addr 0618003B Cnt 0001
1100 0 0 04 005041 000000 1 00000080 SRV_MEM Type 6 Addr 00000025 Cnt 0001
1100 0 0 04 005041 000000 1 00000080 SRV_MEM Type 8 Addr 04001930 Cnt 0004
1100 0 1 04 005041 000000 1 00000080 SRV_MEM Type 6 Addr 00000007 Cnt 0001
1101 1 0 04 005041 000000 1 00000080 SRV_MEM Type 8 Addr 04001940 Cnt 0004
1101 0 0 04 005041 000000 1 00000080 SRV_MEM Type 6 Addr 000000A6 Cnt 0001
1101 0 0 04 005041 000000 1 00000080 SRV_MEM Type 8 Addr 04001958 Cnt 0004
1101 0 1 04 005041 000000 1 00000080 SRV_MEM Type 6 Addr 000000A7 Cnt 0001
1102 1 0 04 005041 000000 1 00000080 SRV_MEM Type 8 Addr 04001968 Cnt 0004
1112 10 8 12 005041 000000 1 00000080 TEMP 28 degC
1121 9 8 02 005041 000000 1 00000080 XFR WR SYS LBA B 0000000075AA L 00000001 …
1129 8 3 02 002241 000000 1 00000080 XFR RD SYS LBA B 000000008E55 L 00000001 …
1143 14 8 02 002241 000000 1 00000080 XFR RD SYS LBA B 000000005702 L 00000001 …
1151 8 8 02 002241 000000 1 00000080 XFR RD SYS LBA B 000000005702 L 00000001 …
1170 19 6 02 002241 000000 1 00000080 XFR RD SYS LBA B 000000005717 L 00000002 …
1176 6 8 02 005041 000000 1 00000080 XFR WR SYS LBA B 000000005717 L 00000002 …
1195 19 6 02 002241 000000 1 00000080 XFR RD SYS LBA B 000000005702 L 00000001 …
1201 6 8 02 005041 000000 1 00000080 XFR WR SYS LBA B 000000005702 L 00000001 …
1220 19 6 02 002241 000000 1 00000080 XFR RD SYS LBA B 000000005702 L 00000001 …
1226 6 8 02 005041 000000 1 00000080 XFR WR SYS LBA B 000000005702 L 00000001 …
1245 19 8 02 002241 000000 1 00000080 XFR RD SYS LBA B 0000000061B7 L 00000008 …
1253 8 5 02 005041 000000 1 00000080 XFR WR SYS LBA B 0000000063A8 L 00000002 …
1258 5 3 02 005041 000000 1 00000080 XFR WR SYS LBA B 0000000061B7 L 00000008 …
1262 4 8 02 005041 000000 1 00000080 XFR WR SYS LBA B 00000002BBC7 L 00000008 …
1281 19 3 02 002241 000000 1 00000080 XFR RD SYS LBA B 0000000060A4 L 00000006 …
1284 3 8 02 005041 000000 1 00000080 XFR WR SYS LBA B 0000000060A4 L 0000000A …
60113 58829 9 34 002221 000000 1 00000080 TCC 0
In the output, we need the last section: RW 32 Cmds. Please note the EC column during its analysis. It is used to
output the command completion code: 80 indicates success, other codes – errors. Info column shows the operation type:
XFR – data transfer, RD – reading, WR – writing, SYS means work with the service area, USR – with the user data
area. 'LBA' is followed by the address in LBA space of the service or user data areas respectively. To identify the
damaged system files (sys file), you need to find the "XFR RD SYS" operations, which completed with errors. Once
you have LBA coordinates of the operation completed with an error (LBA field), you have to find the file associated
with it. That can be accomplished using any of the following two methods.
1) Using the terminal command T>y
1
. After you send the command, the drive will output to terminal a report
similar to the following.
F3 T>y
File Vol FD Location Size Cylinder Hd Sector
---- --- -------- ------------ -------- -------- -- ------
0000 000 fc000042 00000003750a 00000001 00039963 00 0001fa
0001 000 fc001043 00000009a04c 00000001 00037479 01 0001fa
0002 000 fc002044 0000000fcb8e 00000001 0003284b 02 0001fa
0003 000 fc003045 00000015f6d0 00000001 000374ad 03 0001fa
0004 000 fc004046 0000001c2212 00000001 0003829c 04 0001fa
0005 000 fc005047 000000224d54 00000001 00035fab 05 0001fa
0006 000 fc006048 000000287896 00000001 00039b13 00 0001fa
…
File Vol FD Location Size Cylinder Hd Sector
---- --- -------- ------------ -------- -------- -- ------
0000 001 13100201 000040328040 000003c0 ffffffff ff 00ffff
…
0039 001 fd139064 000040606600 00004000 ffffffff ff 00ffff
003a 002 3c23a000 000001423280 00004800 ffffffff ff 00ffff
…
004d 002 fc24d084 000000180000 04000000 ffffffff ff 00ffff
File Vol FD Location Size Cylinder Hd Sector
---- --- -------- ------------ -------- -------- -- ------
0000 003 fd30021b 0000000408b5 001d97f0 00039984 00 000335
0001 003 fd30121c 0000003db094 000c5684 ffffffff ff 00ffff
0002 003 fc30221d 0000000c5684 0003737c 00032784 02 000000
0003 003 fc30321e 0000001281c6 0003737c 000373e6 03 000000
0004 003 fc30421f 00000018ad08 0003737c 000381d5 04 000000
1
Attention! The command may be unsupported in the FW of your drive (an Invalid Diag Cmd message will be
output to terminal). In that case you should use the second method.
