61
Label Component
ACT Turbo/LAN active LED connector
AOL Alert on LAN connector
AUDIO2 Audio connector for USB-audio board
BT1 Battery
BZ1 Buzzer
CD-IN CD-ROM audio connector
CN2 PS/2 mouse (upper) and keyboard (lower) ports
CN3 Network (upper) and USB (lower) ports
CN8 MIDI/game (upper), line-out (left), line-in (middle), and
mic-in (right) ports
CN10 AGP slot
CN19 Parallel (upper), VGA (lower right) and serial port 1
(lower left) ports
COM2 Serial port 2 (COM2) connector (optional)
DIMM1 to 3 DIMM sockets 1 to 3
FAX-VOICE More voice input for modem card
FDC Floppy disk drive connector
FN2 3-pin CPU fan connector
IDELED IDE LED connector
IDE1 IDE 1 HDD connector
IDE2 IDE 2 HDD connector
INTRUDER Intrusion alarm connector
ver3200AAC-0.book Page 61 Friday, March 2, 2001 3:52 PM
