Acer Aspire 8943G Series - Removing the Power Board

Chapter 3 109
Removing the Power Board
1. See “Removing the LCD Panel” on page 104.
2. Peel back the adhesive tape securing the power board cable to the right hinge.
3. Remove two (2) screws from the power board.
Step Screw Quantity Screw Type
Power Board
Disassembly
M2*3 2
