Acer Aspire 8943G Series - Removing the WLAN Module

56 Chapter 3
Removing the WLAN Module
1. See “Removing the Base Door” on page 52.
2. Detach the two (2) cables from the Wireless LAN module.
IMPORTANT:Take note of the Main (black) and Auxiliary (white) connector locations.
3. Remove the one (1) screw. Ensure the cables are well clear of the module.
Step Screw Quantity Screw Type
WLAN Module
Disassembly
M2*3 1
