86 Chapter 3
Removing the RTC Battery
1. See “Removing the Mainboard” on page 84.
2. Use a pair of plastic tweezers to pull the RTC battery off the mainboard.
NOTE: The RTC battery has been highlighted with the yellow circle as shown in the previous image. Please
detach the RTC battery and follow local regulations for disposal.
Removing the Thermal Module
1. See “Removing the Mainboard” on page 84.
2. Disconnect the thermal module fan connector.
