Chapter 3 63
Removing the Keyboard
IMPORTANT: The keyboard is easily warped or damaged during the removal process. Take care not to use
excessive force when removing to prevent damage.
1. See “Removing the Battery Pack” on page 50.
2. Remove the eighteen (18) screws from the lower cover.
3. Turn the computer over. Lift up the keyboard, starting from the top edge.
Step Screw Quantity Screw Type
Lower Cover
Disassembly
M2.5*6 (red callout) 16
M2.5*2.3 (green callout) 2
To Next Page
