126 Chapter 3
Replacing the TV Tuner Cable Assembly
1. Place the TV Tuner port in the chassis.
IMPORTANT:Make sure the port is lined up with the lower cover to ensure proper functioning.
2. Run the TV Tuner cable along the cable channel as shown.
IMPORTANT:Make sure the cable is secured in all cable clips and around all retention guides for proper
installation.
3. Pass the TV Tuner cable through the indicated location in the chassis.
To Next Page
