74 Chapter 3
Removing the Mainboard to Touchpad Cable
1. See “Removing the Upper Cover and LCD Module” on page 66.
2. Turn the upper cover over and push the mainboard to touchpad cable through as shown.
3. Remove the touchpad cable from the adhesive.
IMPORTANT:Take care not to tear the FFC during removal.
4. Peel back the adhesive tape on the connector.
To Next Page
