Acer Aspire Z1620 - Maintenance Flowchart

59
Maintenance Flowchart
The flowchart in Figure 3-1 provides a graphic representation of the module removal and
installation sequences. It provides information on what components need to be removed and installed
during servicing.
Figure 3-1. Maintenance Flowchart
ODD
HOLE
COVER
ODD
Module
Stand
Rear IO
Cover
Rear
Cover
VESA
Bracket
Mainboard
Cover
Camera
Module
VGA
Rear IO
Module
LVDS
IR Cable
Connect
Power SW
Cable
Connect
Speakers
Cable
Connect
Wlan
Module
HDD
Module
Converter
Module
Power
Supply
FAN
Thermal
Module
CPU
Mainboard
DIMM
Main
Framse
Speakers
Power SW_
LED_IR
LCD
Panel
