89
7. Remove screws (A) from camera hinge. (Figure 3-38)
8. Remove camera module (J) from camera hinge.
Figure 3-38. Remove camera module.
9. Disconnect camera cable (D) from module connector (K). (Figure 3-39)
Figure 3-39. Disconnect camera cable.
A
J
K
D
