34
Specifications
Feature Specification
Measurement Range 20 to 600 mg/dL
Result Calibration Plasma-equivalent
Sample Fresh capillary whole blood
Minimum Sample Size 1 µL
Test Time 10 seconds
Power Source One (1) CR 2032 3.0 V coin cell battery
Battery Life 12 months or approximately 1,000 tests
Glucose Units of Measure
The meter is pre-set to either millimoles per liter
(mmol/L) or milligrams per deciliter (mg/dL)
depending on the standard of your country. The
meter will be set to mg/dL by default when sold in
the United States.
Memory Up to 300 records with date and time
Meter Size 85 mm × 54 mm × 20.5 mm
Display Size 35 mm × 32.5 mm
Weight Approximately 49.5 g (with battery installed)
Operating Temperature 41-113°F (5-45°C)
Operating Relative Humidity 20-90% (non-condensing)
Hematocrit Range 30-55%
Data Port 9600 baud, 8 data bits, 1 stop bit, no parity
